Pulse-throwing grate incinerator Working principle

Pulse-throwing grate incinerator
Working principle:
The garbage is fed into the drying bed of the incinerator through the automatic feeding unit for drying,
and then fed into the first-stage grate,
and volatilized and cracked at high temperature on the grate,
and the grate is thrown under the impetus of the pulse air power device,
and the garbage is thrown into the next-stage grate step by step,
at this time, the high-molecular substances are cracked and other substances are burned.
This continues,
until it is finally burned out and enters the ash pit,
and is discharged by the automatic slag removal device.
The combustion-supporting air is sprayed in through the air holes on the grate and mixed with the garbage for combustion,
while the garbage is suspended in the air.
The volatilized and cracked substances enter the second-stage combustion chamber,
for further cracking and combustion,
and the unburned flue gas enters the third-stage combustion chamber for complete combustion;
The high-temperature flue gas heats the steam through the boiler heating surface,
and the flue gas is discharged after cooling.
