Waste incineration equipment: fluidized bed incinerator

Fluidized bed incinerator
Working principle:
The furnace body is composed of a porous distribution plate.
A large amount of quartz sand is added to the furnace,
and the quartz sand is heated to above 600℃,
and hot air above 200℃ is blown into the bottom of the furnace,
so that the hot sand boils,
and then the garbage is put in.
The garbage boils with the hot sand,
and the garbage is quickly dried, ignited, and burned.
The unburned garbage has a lighter specific gravity,
and continues to boil and burn,
and the burned garbage has a larger specific gravity,
and falls to the bottom of the furnace,
and after water cooling,
the coarse slag and fine slag are sent out of the factory by sorting equipment,
and a small amount of medium slag and quartz sand are sent back to the furnace through the lifting equipment for continued use.
